ISCA - Dump Buggy 200lb

Machine Number: 1005

Description

ISCA’s heavy-duty stainless steel Dump buggy is manufactured to the highest possible ‘DIN 9797’ standard and suitable for most standard lifting devices.
Also referred to in the industry as v-edge carts, v-mag carts, vemag carts, vemag buggy, tote bins, euro-style buggies, meat buggy, meat carts, meat trolley or stainless steel buggy – our dump buggies interface with most machines. This includes: standalone dump buggy tippers and tilters, column dumpers, dump buggy scales, dump buggy washing machines, and integrated lifting arms on processing equipment for brands including: Vemag, Handtmann, Seydelmann, GEA Koppens, Hi Tec etc.



Features:
-Heavy-duty walls and a reinforced base plate made from 304-grade stainless steel.
-Continuous welded and beaded construction.
-Rolled edge rim, reinforced with inner solid bar (unlike most competitors’ products).
-Diamond-shaped wheelset for 360-degree movement.
-Lifting lugs as standard – to fit all standard lifting devices.
-Front-mounted drip guard
-Beak tipping v edge as standard.
-Tough and durable white nylon wheels as standard.
-Pushing rear handle as standard.
-Electro-polish finish – inside and out – to facilitate easier product emptying, cleaning, and less adherence to water after washing.
-USDA accepted. Built to the highest DIN 9797 Standard.
-Non-branded dump buggies available (for resellers)



Buy ISCA Dump Buggies and buy once – these buggies are built to last and built to withstand the harshest of environments. ISCA supplies end users and re-sellers with the highest quality dump buggies and will not be beaten on quality, price, convenience or service.



Videos

Technical

-Stainless steel – AISI 304
-Wall Gauge 14  –  5/64” (2mm) 304-grade stainless steel
-Base Gauge 7 – 3/16” (5mm) 304-grade stainless steel
-Dump buggy dimensions – See drawing attached
-Dump buggy weight – 66.2lbs (30kg) (+/- 0.2)


Customized options available (please ask on our inquiry form):

-Detachable base – an ultra-hygienic option
-Wheel color
-Valve drain
-Perforated walls
-Filter inserts
-Extended push handle
-Non-branded dump buggies (for resellers)
